The Pipe Clamping Range is Wide

The pipe clamping range is wide,Round tube φ10-φ10, and Square tube side length is 10 * 10mm-350mm * 350mm. Support the cutting of various shapes of pipe materials, such as I-beam, channel steel, angle steel, elliptical pipe, waist pipe, multi-deformed pipe, etc.

Integrated Machine Bed

The unique industrial structure design gives it maximum stability and higher vibration resistance and damping quality. The compact spacing of 650mm ensures the agility of the chuck and the stability during high-speed driving.

Pneumatic roller support

Fixing the pipe effectively solves the deformation problem in the cutting operation of the long pipe.

Tube Pro

The professional cutting software for processing various types of pipes. Through the collection and processing of various real-time information, it can achieve high-precision cutting and achieve higher efficiency processing.

Efficient Auto-lubrication system

Manually set the number and time interval of automatic lubrication according to the length of equipment use;Automatic lubrication of guide rails, sliders, gears, racks, and other components, recycling, and centralized processing of lubricating waste oil.
Product Video
Technical Parameter
mm
inch
Model
 OR-TG6035 OR-TG6020 OR-TG7035
Laser Output Power
1000w-6000w 1000w-6000w 1000w-6000w
Effective Cutting Diameter Of Round Tube
φ15-φ350mm φ15-φ230mm φ15-φ350mm
Effective Cutting Diameter Of Square Tube
□15-□350mm □15-□230mm □15-□350mm
Positioning Accuracy
±0.05mm ±0.05mm ±0.05mm
Repeat Positioning Accuracy
±0.05mm ±0.05mm ±0.05mm
Maximum Simultaneous Positioning Speed
80m/min 120m/min 80m/min
Maximum Acceleration
0.8G 1.5G 0.8G
Model
 OR-TG6035 OR-TG6020 OR-TG7035
Laser Output Power
1000w-6000w 1000w-6000w 1000w-6000w
Effective Cutting Diameter Of Round Tube
φ0.59inch-φ13.779inch φ0.59inch-φ9.05inch □0.59inch-□13.779inch
Effective Cutting Diameter Of Square Tube
□0.59inch-□13.779inch □0.59inch-□9.05inch □0.59inch-□13.779inch
Positioning Accuracy
0.00197inch 0.00197inch 0.00197inch
Repeat Positioning Accuracy
0.00197inch 0.00197inch 0.00197inch
Maximum Simultaneous Positioning Speed
80m/min 120m/min 80m/min
Maximum Acceleration
0.8G 1.5G 0.8G
Cutting Sample
