Brand New Double-beam Bed Structure
Self-developed stopper plug-in double-beam design
Anti-deformation, low vibration, guaranteed accuracy
Can achieve long-term cutting without deformation
Ensuring long-term stable operation of the equipment
Highly Integrated Design
One-key automatic door opening method
Equipped with a pull-up and down material structure
High equipment space utilization
Production is safer and more efficient
European Safety and Environmental Standards
Fully enclosed enclosure design
Equipped with OD4+ laser protective glass
Effectively reduces shielding of laser radiation
Layered protection, safety guaranteed
High-precision Transmission System
Adopting ball screw drive
Direct drive, small clearance, high precision
Ensure stable and accurate operation of the equipment
Product Video
Technical Parameter
mm
inch
Model
 OR-S 1510 OR-S 1313 OR-S 1309
Laser Power
1000w~3000w 1000w~3000w 1000w~3000w
Working Area
1530*1050mm 1330*1350mm 1330*950mm
Accuracy Of Positioning
±0.03mm ±0.03mm ±0.03mm
Repositioning Accuracy
±0.02mm ±0.02mm ±0.02mm
Max Movement Speed
100m/min 100m/min 100m/min
Max Acceleration
0.6G 0.6G 0.6G
Model
 OR-S 1510 OR-S 1313 OR-S 1309
Laser Power
1000w~3000w 1000w~3000w 1000w~3000w
Working Area
60*41inch 52*53inch 52*37inch
Accuracy Of Positioning
±0.00118inch ±0.00118inch ±0.00118inch
Repositioning Accuracy
±0.00079inch ±0.00079inch ±0.00079inch
Max Movement Speed
100m/min 100m/min 100m/min
Max Acceleration
0.6G 0.6G 0.6G
Cutting Sample
Contact Us
If you want a price, fully catalogue or other informations, pls contact us
