Split mortise and tenon structure bed

Heavy-duty gantry split plate welding machine bed, tenon and tenon structure, equal-strength welding, stability is improved by more than 65% compared with similar products.

Beam safety light curtain

The beam part is equipped with safety gratings to ensure the production safety of employees.

Exhaust smoke and dust, safe and environmentally friendly

The lower area of the cutting area is equipped with large-caliber partitioned dust removal, with a powerful gathering exhaust system and a follow-up dust removal design, which can remove dust more thoroughly, zero pollution and more environmentally friendly.

Single platform modular design

Integrated modular blade type support design, realizing rapid replacement of blades without stopping the machine, easy maintenance, and saving user costs.

Linear contact foot

Oree's patented foot design adopts line contact mode to ensure the stability of the bed during the cutting process, and it is more convenient to adjust the accuracy of the bed.

Visual feed function

With the visual replenishment function, novice operators can track the metal sheet through the operation interface and replenish the layout to ensure accurate cutting. Maximize the use of surplus plates, and increase the utilization rate of plates to 90%.
Technical Parameter
mm
inch
Model
OR-G24023
Laser power
8000-30000w
Processing area
24100*3200mm
Positioning accuracy
±0.05mm
Repeated positioning accuracy
±0.05mm
Maximum cutting speed
80m/min
Maximum acceleration
2.5G
Model
OR-G24023
Laser power
8000-30000w
Processing area
948.81*125.98inch
Positioning accuracy
±0.0019685inch
Repeated positioning accuracy
±0.0019685inch
Maximum cutting speed
80m/min
Maximum acceleration
2.5G
Cutting Sample
